E KIDS-20 2024
E KIDS-20 2024
COMING SOON!
250W Hub Motor
The EKIDS-20 features a robust 250w motor capable of reaching speeds of approximately 25kph, striking a balance between excitement and safety.
24V 10Ah
Battery
250W
Hub Motor
25 KPH
Top Speed
Up to 32 km
Riding Range
90 kg
Payload Capacity
105 ~ 152 cm
Recommended Rider Heights
Innovative Battery Design
We've innovated this battery casing independently, securing a patent for its unique design. The bike frame is meticulously aligned with the battery box, highlighting our dedication to seamless integration and visual coherence.
3 Speed Options
The gear selector provides riders with three speed options: 12, 18, and 25 KPH, catering to various riding scenarios with flexibility. The throttle activates once the speed reaches 3km/h, ensuring a safe and gradual acceleration.
Brake System
The EKIDS-20 is equipped with a front and rear dual-disc brake system, providing an added layer of safety and security for children while they enjoy their rides.
Specification
- Battery: 24V 10Ah with EUNORAU-designed battery casing
- Range: 32 KM
- Motor: 24V 250W rear motor
- Total Payload Capacity: 90 KG
- Recommended Rider Heights: 105 ~ 152 CM
- Age Guideline: Ages 8 and above
- Maximum Speed: 3 speed limits on the handlebar ( 12, 18, 25 KPH )
- Charger: AU standard 2.0 A smart charger
- Display: No display equipped
- Battery Type: Lithium-ion
- Battery Charging Time: 4 - 5 hours
- Box Dimensions: (cm) 131 L x 24.5 W x 74.5 H
- Weight: 17 KG
Geometry
Components
- Tires: 20*1.95", front & rear integral wheel
- Fork: Integrated die-cast aluminum alloy
- Brake lever: Disc brakes levers with motor cutoff switch
- Shifter: Single speed
- Brake Rotors: 160mm disc brake rotors
- Throttle: Half-twist throttle, activated after reaching 3 km/h
- Crank: 140mm forged aluminum alloy
-
Chainring: 32T chain-wheel crank
- Freewheel: 16T single speed freewheel
- Frame: Aluminum alloy 6061
- Sensor: Cadence sensor
- Handlebar: Comfortable stem
- Light: Wheel reflector
-
Tool: Included
