FAT-HD
FAT-HD
The EUNORAU FAT-HD is one of the more powerful productions eBikes on the market today. Built entirely around the Bafang BBSHD 1000w motor, this bike packs a wallop in torque and power
Utilizing a mid-drive motor, the FAT-HD can produce an immense amount of torque and move the rider up very steep inclines without hesitation.
1000 Watt Mid-drive Goes the Distance
The EUNORAU FAT-HD is one of the more powerful production eBikes on the market today. Built entirely around the Bafang BBSHD 1000w motor.On the features list we have the two height pannier rack has a wide plate and the spring tensioned arms for holding small, pliable items, and the metal fenders are a great plus.Metal fenders stay in place much better, especially when encountering loose and packed terrain such as mud. The strong 13ga spokes are well fitted for the size and torque of the system, and the wheel punch-outs make for a great look on the bike overall.And it is equipped with fat tyres, front suspension and a hefty battery to help it power through the mud, snow, sand and pretty much anything else you can throw at it.
Bafang M615 BBSHD Mid-Drive System
The Bafang M615 system features the G320 electric motor with over 1500 watts of peak power, 160Nm of torque and cadence-sensing assist. This allows you to span cities, climb hills, and explore all the places you want to go with ease.
Front Suspension Fork
Absorbing a lot of jarring bumps and shocks on rugged routes, the RST fork helps maintain your energy, helping you focus on riding better and faster.
Specification
- Battery: 48V/15.6Ah
- Range: 96 km with upgraded 25AH battery
- Motor: 48V1000W BAFANG brushless mid motor with 160 N.m torque
- Total Payload Capacity: 170 kg
- Recommended Rider Heights: 169~193 cm
- Maximum Speed: 45 km/h
- Charger: AU standard 2.0 A smart charger
- Controller: 48V
- Display: 500C LCD display
- Weight: 35.7 kg
- Pedal Assist Intelligent: 0~5 level pedal assist
- Box Dimensions: (cm) 156 L x 34.5 W x 85 H
Components
- Tyres: Kenda krusade sport tyres 26" x 4.0"
- Brake Lever: PROMAX made hydraulic disc brakes with motor cutoff switch
- Rear Light: Taillight
- Shifter: Shimano derailleur 7 speed gear shift system
- Brake Rotor: EUNORAU Design Front 180mm & Rear 160mm Hydraulic Disc Brakes
- Throttle: Thumb throttle
- Gear sensor: Bafang BBSHD gear sensor
- Crank: 170mm forged alloy
- Cassette: Shimano 12-28T
- Fork: RST GUIDE 100mm travel
- Frame: 6061 aluminum alloy
- Pedal: Aluminum alloy pedal with reflectors
- Grips: Rubberized Slant waffle pattern, friction mounted
- Front Light: LED light
- Saddle: Comfort Saddle, Height to Ground 86-108 cm
-
*NOTE: this ebike is sold with the left brake lever controlling the front brake, and the right brake lever operating the rear brake.
Tool: Included
Chainring: 46T EUNORAU chain-wheel With protection
Rims: 26 inch black alloy wheels
-
Geometry
